169-A ion fan introduction and technical parameters
-
169-A ion fan introduction and technical parameters
-
-
The benchtop ion fan eliminates static charges from a wide range of targets or areas that are not easily accessible. It is characterized by rapid elimination of static electricity, large coverage of ion wind, ion trap cleaner, ion generation indicator, continuous adjustment of wind speed, built-in fan and high voltage power supply, ion balance voltage of 0V ± 10V. Installation method: desktop, hanging. It is an ideal static eliminator for precision electronic products, electronic assembly, pharmaceutical manufacturing assembly lines, printing, packaging and small product molding.
-
-
Technical Parameters:
-
-
Operating Voltage: 110V/60Hz or 220V/50Hz;
-
-
Current Consumption: 0.25A or 0.12A;
-
-
Operating Temperature: 0-50 ° C;
-
-
![169-A ion fan introduction and technical parameters](/uploads/jinghuashebei/860X878_169lizi_fengji_jieshao_tu-001.jpg)
-
-
Air Coverage (airflow area): 40cm × 60cm;
-
-
Size (outer size): 90mm (L) × 170mm (W) × 260mm (H);
-
-
Weight: 3kg;
-
-
Air Volume: 45~110CFM;
-
-
Ion Balance: 0V ± 10V.
-
-
Test Results:
-
-
Decay Test Conditions: Operating Voltage: 110V/220V Testing Voltage: 1KV to 100V;
-
-
Temperature (ambient temperature): 22 ° C;
-
-
Distance: 300mm; Decay time: Positive: 1.2s; Nefative: 1.2s;
-
-
Distance: 600mm; Decay time (Positive): 2.5s; Nefative (negative): 2.4s;
-
-
Distance: 900mm; Decay time: Positive: 4.0s; Nefative: 3.9s.
-
